Application:  Purifier is the efficient equipment for purifying and grading semolina and middling in wheat flour and corn milling.

Features:

  • Up-to-date technology with continuous improvement of design
  • Aluminum alloy extrusion profiles for screen track and screen frames
  • Reversible sliding brushes for screen self cleaning
  • Dual vibrator driving system
  • Durable rubber spring supports
  • Aluminum construction for substructures to reduce the deck weight
  • Welding and assembly jigs and tooling for precise assembly
  • Powder coated finish for best quality and duration
Model​​​​                    Capacity (kg/h) Coarse Capacity (kg/h) Fine Power (kW) Air Volume (m³/min) Weight (kg) Dimensions LxWxH (mm)
FQFD 49×2×3
1,400-2,800
600-1,400
2×0.25
40-70
1,020
2,700×1,290×1,750
FQFD 60×2×3
1,680-3,370
720-1,680
2×0.25
55-90
1,220
2,750x1,490×1,850
