Application: Seed Treaters are for seed treating with chemicals before planting.
This series continuous seed treaters are widely used for seed treating with chemicals, typically fertilizers, antimicrobials, fungicides or pesticides, plant growth regulators, colorants and fillers.
The chemical dressing agent is applied on the grain a thick layer in a continuous flow. Several seed dressing agents can be dosed at the same time. Seed treatments can be more environmental friendly for using pesticides as the amounts used can be very small. The dressing layer on seeds can improve the stress and disease resistance and speed up the germination. Usually add color to make treated seed less attractive to birds and easier to see and clean up if spilt.
They are suitable for vary types of volume seeds: grain, cotton, vegetable, forestry, flower, etc.
Capacity: 5TPH to 10TPH (200 to 400BPH ) based on wheat (≥99% quality seeds, ≤0.1% broken)
Features:
- Impeller feeder and level sensor featuring continuous and adjustable feeding with accurate measuring
- Automatic and manual liquid supply options
- Two stages seed and dressing liquid mixing systems for gentle seed handling and uniform dressing layer
- Powered soft brush cleaning system to remove materials and liquids on the inner wall of mixing chamber for easy clean up
- Compact and enclosed design
- Continuous and reliable processing with high capacity
- Fully automated PLC control system to improve productivity and management
- Powder coated finish for best quality and duration
| Model | Capacity, wheat (t/h) | Dimensions L×W×H (mm) | Power (kW) | Dosing ratio |
|---|---|---|---|---|
C5BG-5 | 5 | 2,300×800×2,500 | 2.42 | 1:25 - 1:120 |
C5BG-10 | 10 | 2,230×1,040×3,080 | 4.09 | 1:25 - 1:120 |
