Application: blend all ingredients uniformly for high quality feeds.
Capacity: 250kg/batch to 2,000kg/batch
Features:
- Patented dual layer paddle rotor provides mixing uniformity ≥ 95% (CV≤5%)
- Fast mixing process: 45-90 seconds mixing time
- Equipped with large return air duct to reduce dust and prevent material segregation
- Full-open discharge ensures residual rate ≤0.1% preventing cross contamination
- Well sealed discharge door and shaft end to ensure no leakage
- Large access door for easy cleaning and maintenance
- Integrated safety switches ensure safe operation
- Heavy duty steel construction preventing vibration
| Model | Volume (m³) | Power (kW) | Capacity (kg/Batch) | CV (%) | Weight (kg) | Dimensions LxWxH (mm) |
|---|---|---|---|---|---|---|
SJHS 0.5 | 0.5 | 7.5 | 250 | ≤5 | 940 | 1,624x1,515x1,552 |
SJHS 1 | 1 | 11/15 | 500 | ≤5 | 2,330 | 2,730x1,373x2,000 |
SJHS 2 | 2 | 18.5/22 | 1,000 | ≤5 | 2,490 | 3,186x1,717x2,490 |
SJHS 4 | 3 | 37/45 | 2,000 | ≤5 | 7,220 | 3,838x2,163x2,972 |
