Application: Gravity Destoner is widely used for removing grain alike size stone and other heavier impurities from grains.

Capacity: 1TPH to 20TPH (40BPH to 800BPH)

Features:

  • Modular design for a series models
  • Stacked dual decks for high capacity and superior cleaning outcome
  • Adjustable screen deck slopes with integration of air speed for various of grains
  • Screen deck vibrating strike is adjustable for process flexibility
  • Negative air system for clean working environment
  • Patent design for preventing grain back flow at stone discharge  (Patent: ZL201020577278.2)
  • User friendly distinctive air blow back assembly (Patent: ZL201120180371.4)
  • Dual vibrate motor driving system with low power consumption, low noise, less maintenance
  • Durable and maintenance free rubber spring supports
Model Capacity (t/h) Deck Width (cm) Air Vol. (m³/h) Power (kW) Weight (kg) Dimensions L×W×H (mm)
TQSF 43
1-1.5
43
3,000
0.25 x 2
215
1,270×700×1,600
TQSF 50
2-4
50
4,000
0.25 x 2
230
1,420×780×1,800
TQSF 60
3-5
60
4,500
0.25 x 2
280
1,450×876×1,800
TQSF 80
5-7
80
6,000
0.25 x 2
340
1,450×1,046×1,800
TQSF 100
7-9
100
8,000
0.25 x 2
400
1,500×1,246×1,900
TQSF 125
9-11
125
10,200
0.25 x 2
500
1,470×1,496×1,900
TQSFB 125
15-18
125
12,000
0.25 x 2
650
1,649×1,714×2,083
TQSF 150
11-14
150
12,000
0.25 x 2
600
1,580×1,746×1,900
TQSFB 150
18-20
150
15,000
0.25 x 2
760
1,649×1,964×2,083
TQSF 175
14-18
175
15,000
0.25 x 2
750
1,470×1,990×1,900
TQSF 200
16-20
200
17,000
0.25 x 2
1,000
1,470×2,292×1,900
TQSF 250
20-22
250
20,400
0.25 x 2
1,050
1,470×2,835×1,900
