Application:  cooling fresh pellet feed efficiently to room temperature for further processing.

Capacity: feed pellet 8TPH to 20TPH

Features:

  • Round cooling hopper construction for uniform pellet cooling process. No material hanging and dead corners
  • Suitable for pellets with length less than 40mm
  • Cooled pellets temperature at the cooler discharge is no higher than 3°C above ambient
  • Moisture drop is not less than 3.95%
  • Pneumatic discharge system for energy saving up to 80%
  • Rub or squeeze free at the discharge to avoid pellet breaking
  • Larger cooling air intake for energy saving up to 10%
Model Power (kW) Capacity (t/h) Temp. After Cooling Weight (kg) Dimensions LxWxH (mm)
SKLNW 20
0.75
8-15
≤RT+3°C
2,335
4,776x2,444x2,312
SKLNW 25
0.75
15-20
≤RT+3°C
2,685
4,848x2,874x2,732
